30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
- 180º Glass-to-Glass
- Beveled Edges
- Reliable Performance at a Value Price
Max Weight 3 Hinges
120 Lbs. (54 kg) - Width 32" (813 mm)
Max Weight 2 Hinges
80 Lbs. (36 kg) - Width 28" (711 mm)
Using two hinges with 5/16" (8 mm), 3/8" (10 mm), and 1/2" (12 mm) glass the hinge will hold up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm).
Using three hinges with 5/16" (8 mm), 3/8" (10 mm), and 1/2" (12 mm) glass the hinge will hold up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).
Glass Thickness Range: 5/16" (8 mm) to 1/2" (12 mm) Tempered Safety Glass
Construction: Solid Brass
Hinge Swings: 90º In and 90º Out
Closing Type: Self-Centering when within 10º of closed position.
Includes: Gaskets, Screws, and Glass Fabrication Dimensions
Custom finishes are available on request. Contact the DK Hardware Sales Shower Door Department. Important Notes: CRL Shower Door Hinges are designed for residential or hotel shower use. If hinges are to be used for other than their intended purpose, approval must be obtained from the CRL Shower Door Technical Sales Department. Use only the template included with this hinge. Cut-out dimensions for CRL hinges may not match those of other brands.
