Designer Series Glass To Glass Door Hinge 135 Degree Gloss White

Roll over image to zoom in

Brixwell H135GTGW Designer Series Glass To Glass Door Hinge 135 Degree Gloss White

Item #: H135GTGW by Brixwell

See reviews See reviews

In Stock $113.68 /each

SAVE UP TO 11.37

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business day
QTY
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

  • Adjustable Feature Allows for Adjustment of Door
  • The hinge features self-closing of the door hence keeping the door always in a closed position when not in operation
  • The door closing position can be adjusted even after the installation of the door especially useful for those unaligned door situations
  • Closing Position After Installation
  • Matching Finish Stainless Steel Allen Style Clamp Screws (Phillips Screws Available Upon Request)
  • For convenient installation, the hinge comes with Allen Wrench a handheld hardware tool to fix screws
  • Self-Centering 0° Return with Adjustment Up to 30° In or Out
  • Solid Forged Brass Construction
  • Precision Machined 300 Series Stainless Steel Components
  • Dual Precision Wound Stainless Steel Return Springs
  • Self-Closing from 25 Degrees
  • Mouse Ear Design
  • Designed for 3/8" and 1/2" (10 and 12 mm) Glass
  • Wall Mount Hinges Include Matching Finish Stainless Steel Mounting Screws
  • Allen Wrench Included
  • Rated at 40 lbs (18 kg) per Hinge

Height

4

Finish

Gloss White

Material

Solid Forged Brass

Type

135 Degree

Mounting Style

Glass to Glass mount

Pack Size

1

Angle Degree

135 Degree

Designed For

3/8" and 1/2" (10 and 12 mm) Glass

Self-Closing

From 25 Degrees

Other Specifications

Maximum door weight: - 2-hinge - 80lbs (36kg) - 3-hinge - 120lbs (54kg) Maximum door width: - 2-hinge - 30" (762mm) - 3-hinge - 36" (914mm)

Hardware Includes

Matching Finish Stainless Steel Allen Style Clamp Screws and Allen Wrench

Glass Fabrication Required

Cutout

Edge Profile

Square

Adjustable

No

Self-Centering

Yes

5 Degree Pre-Set

No

Glass To Glass Angle (Degrees)

135

Max Door Width - 3 Hinges (IN)

36

Max Door Weight-2 Hinges (Lbs)

80

Glazing Thickness (Inches)

1/2, 3/8

Max Door Width - 2 Hinges (IN)

30

Max Door Weight-3 Hinges (Lbs)

120

The Designer Series Glass to Glass Door Hinge is made with high-grade metal components, which makes it a durable product for consumption. The hinge will not only hold the door together safely but also blend in with the decor as these are available in a variety of polishes to suit your requirements.
