Eaton 1107W-BOX Decorator Receptacle Duplex 15-Amp Grounding (NEMA 5-15R) - White
Item #: 1107W-BOX by Cooper Wiring Devices
UPC #: 032664752469
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Mounting Type
Wall
Operating Temperature
-20 to 60 deg C
Frequency Rating
60 Hz
Current Rating
15 A
Dimensions
42 in L x 130 in W x 069 in D
Number of Poles
2
Nomenclature
1107W-BOX WHT RECPT 15A DECORA
Material
PVC
Contact Material
Brass
Strap Material
Steel
Number of Wires
3
Wire Size
14 to 10 AWG
Wiring Type
Back Side
NEMA Configuration
5-15R
Color
White
Configuration
2-pole, 3-wire, grounding
Product Overview
RECPT DUPLEX STD DECR 15A WHT
Longer, wider strap provides 40 percent more contact area to wall board. Virtually eliminates floating installations. Built-in wire stripper for number 14 and number 12 wire and wire looper for pre-looping. Combination slot/Phillips head mounting and terminal screws for installation with power screwdrivers. Terminal screws backed out - ready for wiring. Side wire terminals accept up to number 10 solid or stranded wire. Push-in terminals accept number 14 solid wire. Temperature range of -40 to 65 degrees C. Meets all UL 498 requirements, (file no. E15058), Fed. Specs. WC-596G, NOM Certified, CSA Certified, C22.2 no.42. Standard Grade: (file no.6914) (6233-01). Meets flammability requirements per UL94, V2 rated. 15 amp, 125 volt.
