Gedore 8.11.6981 8612-300 Electronic tester DREMOTEST E 9-320 Nm

Item #: 8.11.6981 by Gedore

Brand: Gedore

UPC #: 4002805928349

See reviewsSee reviews
See reviews summary

$1,824.31

1,967.96 /each
SAVE UP TO 182.43
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Vde certified

31.12.1899

Total width [mm]

118 mm

Total length [mm]

150 mm

Total height [mm]

126 mm

Torque range (min./max.) [n·m]

9 N·m - 320 N·m

Torque range (min./max.) [lbf·ft]

7 lbf·ft - 236 lbf·ft

Torque (min.) [n·m]

9 N·m

Torque (min.) [lbf·ft]

7 lbf·ft

Torque (max.) [n·m]

320 N·m

Torque (max.) [lbf·ft]

236 lbf·ft

Reach registration available

31.12.1899

Net weight [kg]

3 kg

Graphic display

31.12.1899

Drive connector hexagon female (metric)

17,0

Customs tariff number

90318080

Adaptor

3/8", 1/2"

1000 v insulated

31.12.1899

Measurement accuracy

± 1 % Toleranz bei allen Ablesewerten, ± 1 Digit

Interface

RS-232

Overload Protection

31.12.1899

Product Overview
Easy to operate, electronic torque tester with integrated torque transducer (DMS), 5 models in the range from 0.2 to 3150 N m, With fixed hexagon female drive 1/4", 10, 17, 36, 46 mm or 1.1/2" square drive adaptor (model dependent), With 1/4", 3/8", 1/2", 3/4", 1" square drive adaptor or bit adaptor (model dependent), High measurement accuracy: +/- 1 % tolerance of reading, +/- 1 digit, Break-Point-measurement (1st peak), Autoreset, Can be switched from N m to lbf ft, Serial interface RS232, Optionally available: adaptor for cigarette lighter socket (12 V), no. 8612-390, Optionally available: Car adaptor for 12 Volt power supply (No. 8612-390), software for plausibility check (Code 2834391), Scope of delivery: Electronic torque tester, RS232 Cable, Power supply unit with EURO plug (UK, US, AUS-adaptor on request), 100 - 240 V, 50 - 60 Hz, max. 500 mA (note type plate), 2 socket wrench inserts (size and drive depending on model), Adaptor for No. 8612-3150, Operating instructions, Packaging, Test certificate
