Brixwell H-PIVGTGA-PBClick To Copy Adjustable Glass To Glass Mount Shower Door Pivot Hinge 3/8" and 1/2" Glass Thickness Polished Brass Finish

The Adjustable Glass-to-Glass Mount Shower Door Pivot Hinge in Polished Brass finish is designed for frameless shower enclosures requiring a connection to overhead fixed transoms. Made from solid forged brass with precision-machined stainless steel internal components, this hinge ensures strength, reliability, and smooth performance in shower hardware, glass hardware, and door hardware applications. It features dual precision wound stainless steel return springs that deliver self-centering 0 degree return and self-closing from a 25 degree door angle. Its adjustable design allows installers to set the closing position up to 90 degree in or out after installation. Using the included 3mm hex wrench, screws can be loosened, the door repositioned, and then re-tightened to achieve precise alignment. The non-mouse ear design simplifies adjustment while maintaining a clean frameless appearance. Designed for Euro Header and Elite Header systems, this hinge is compatible with 3/8" (10mm) and 1/2" (12mm) tempered glass, requiring fabrication cutouts for proper fit. Each hinge is rated at 40 lbs, with two hinges supporting shower doors up to 120 lbs and a maximum width of 36". For weight guidance, 3/8" glass is 5.05 lbs/sf while 1/2" glass is 6.40 lbs/sf. Dimensional specifications include glass edge to hole spacing of 1-13/16" (top and bottom) and end to end hole spacing of 3-1/4". The square corner and edge profile deliver a modern look in frameless hinge applications. Hardware includes stainless steel hex clamping screws, crosshead screws, and a hex wrench in matching finish. This hinge integrates into pivot hinge, glass mount, and frameless hinge systems, making it suitable for both residential and commercial shower projects.
