Hafele 924.18.917 Concealed Hinge, Tectus TE 240 3D Concealed, for interior doors, 3D adjustable, Bronze metallic Bronze colored, metallic, powder coated

Item #: 924.18.917 by Hafele

See reviewsSee reviews
See reviews summary
In Stock

$200.72

/each
SAVE UP TO 20.07
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 6 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Material

Aluminum, Steel

Model

TE 240 3D

Door Thickness

≥25 mm

Opening Angle

180 °

Bearing Type

Friction bearing, maintenance-free

Flange Shape

Rounded

Max. door weight for 2 hinges

40 kg

For frame type

Steel frame, Wooden frame, Aluminum frame

Model series

TE 240 3D

Thrust ring diameter

30 mm

Adjustment facility

3D, Side: ±3 mm, Height: ±3 mm, Closing pressure: ±1.5 mm

Order reference

"Energy" version for permanent and invisible energy transmission from the door frame to the door leaf optionally available.

Area of application

Used in door frames made out of hollow metal or wood for flush doors

Flange height

155 mm

Flange width

18 mm / 21 mm

Door weight max.

88 lbs

Router bit diameter

5/8"; Guide: 1 3/16"

For door thickness min.

1 1/8"

Color/Finish

Bronze colored, metallic, powder coated

Mounting

For DIN left and DIN right hand use

Grade

2|7|2|0|1|3|0|7

Standard

Certified in compliance with EN 1935:2002

Door thickness min.

1"

Product Overview
Concealed Hinge, TECTUS TE 240 3D 3D adjustable, size 155 mm, Bronze metallic Optional Accessories: P-00863028;P-00862990;P-00863130
