Concealed Hinge, TECTUS TE 645 3D concealed, 3D adjustable, size 280 mm, Matt deep black (RAL 9005) Black, matt, powder coated

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Hafele 924.19.083 Concealed Hinge, TECTUS TE 645 3D concealed, 3D adjustable, size 280 mm, Matt deep black (RAL 9005) Black, matt, powder coated

Item #: 924.19.083 by Hafele

See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features
  • Used in door frames made out of hollow metal or wood in flush interior doors
  • Suitable for left and right hand applications

Grade

4|7|7|1|1|3|1|14

Material

Aluminum, Steel

Model

TE 645 3D

Door Thickness

≥40 mm

Opening Angle

180 °

Flange Shape

Rounded

Standard

Certified in compliance with EN 1935:2002

Max. door weight for 2 hinges

300 kg

For frame type

Steel frame, Wooden frame, Aluminum frame

Model series

TECTUS

Thrust ring diameter

30 mm

Adjustment facility

3D Continuous, Side: ±3 mm, Height: ±3 mm, Closing pressure: ±1 mm

Area of application

For wooden, steel or aluminium frames for flush doors

Flange height

280 mm / 260 mm

Flange width

36 mm / 34 mm

Router bit diameter

24 mm

Color/Finish

Black, matt, powder coated

Mounting

For DIN left and DIN right hand use

Product Overview
Concealed Hinge, TECTUS TE 645 3D concealed, 3D adjustable, size 280 mm, Matte deep black (RAL 9005) Optional Accessories: P-00863028;P-00862990
