Hafele 941.04.005 Sliding door fitting, Hawa Junior 100 Z /100 Z Pocket, set 1,500 mm 100 Z Pocket Empty Empty

Item #: 941.04.005 by Hafele

See reviewsSee reviews
See reviews summary
In Stock

$442.87

/each
SAVE UP TO 44.29
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 8 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features
  • low opening force easy and convenient operation
  • Barrier-free due to low operating force
  • new, Hawa SoftMove 100 soft and self closing mechanism
  • Push-to-Open function due to spring buffer, for ejecting the fully inserted door from the wall pocket

Number of Doors

1.00

Installation reference

The door can be installed and removed from the front or the side. Pocket door solution: subsequent disassembly of the running track is possible without opening the wall, running gear and soft and self closing mechanism can be removed, Stopper position in the wall pocket, readjustable.

Controller installation options

Ceiling installation, Wall mounting, Wall pocket solution

Door processing

for screw fixing

Area of application

For 1-leaf and 2-leaf sliding doors

Version

Empty

For door weight

≤100 kg

Supplied with

2 running gears 2 two-way suspensions 1 clear threshold floor guide 60 mm 1 SoftStop with retaining spring 1 wall buffer Accessories

Adjustment facility

Height adjustment facility: -4 – 4 mm, Door side adjustable,Track buffer with adjustable retaining spring

Soft closing mechanism

Empty

Running position

Top

Number of doors per system max.

1 to 2

For door material

wood

For Door Width

≤1,500 mm

For Door Thickness

35 – 80 mm

For Door Height

≤4,000 mm

Installation

Suspension with screwed on two-way suspension

Model

100 Z Pocket

Max Door Weight

220.00 lb

RequiredProducts

true

Product Overview

Note on door width
The max. door width for the pocket door solution is 1,500 mm. Required Products: 940.80.140;940.80.160;940.80.180;940.80.200;940.80.220;940.80.250;940.80.300;940.80.400;940.80.600;941.04.600;941.04.601;941.04.602;941.04.603;941.04.604;941.04.605;941.04.606;941.04.607;941.04.608;941.04.609;940.41.130 Optional Accessories: P-00876385;P-01550895;P-00876473;P-00877180;P-01550911;P-00875932;P-01550923;P-01550924;P-00875933;P-01550942;P-01319634;P-00876698
