Hafele 403.20.010 Sliding door fitting, Hawa Libra 20 Synchro H IF/VF, set For vertical sliding doors with 2 synchronized, bi-parting doors, for door weights up to 44 lbs., Infront/Vorfront Rollers: Plastic
Item #: 403.20.010 by Hafele
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Installation
Running gear and guide for screw fixing
For Door Height
≤1,000 mm
Cabinet version
with synchronized running doors
For door material
wood
Number of doors per system max.
2
Model series
Libra
Running position
Bottom, top on the side
Number of rollers
1
Supplied with
4 sliding hardware with cam adjustment 4 sliding hardware with spring 2 reverse roller 2 door safety 4 rope brackets 2 tightening bolt for rope bracket 2 pcs of rope 2 cover caps 8 covers for sliding hardware
For door weight
≤20 kg
Order reference
In general, doors should be the same size, and must weigh the same as they need to counter balance each other
Counterweight
The bottom door represents the counterweight for the top door, therefore both doors must be of equal weight
Set
Set without tracks
For side panel thickness
min 16 mm
Area of application
2 synchronized running doors
Door width max.
Max. 63"
Door weight max.
44 lbs
Material/finish
Rollers: Plastic
Side panel thickness min.
5/8"
For door thickness min.
5/8"
Type of opening
linear
Number of Doors
2
For Door Thickness
≥16 mm
For Door Width
≤1,600 mm
Max Door Weight
44.00 lb
RequiredProducts
true
Product Overview
Sliding door fitting, Hawa Libra 20 Synchro H IF/VF, set For vertical sliding doors with 2 synchronized, bi-parting doors, for door weights up to 44 lbs., Infront/Vorfront
