30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Weight
Max. door: 79 lbs.
For Door Height
Max: 7' 2 5/8"
For Door Thickness
19 – 25 mm
For Door Width
Max: 3' 3 3/8"
Cabinet version
with sliding doors with zero clearance
For door material
wood
Number of doors per system max.
2 to 3
Model series
Clipo
Running position
Top
Number of rollers
4
Soft closing mechanism
with clip-in door stopper
Adjustment facility
Height adjustment: ±2 mm, Height adjustment +/- 2 mm (1/16")
Supplied with
4 Running gears 4 Housing pieces 1 soft stop 2 guides 4 track stoppers
For door thickness max.
1"
Order reference
Please order running and guide tracks separately. Soft closing mechanism on one side is possible from pitch length of min. 260 mm, both sides from 460 mm. Please order soft closing mechanism set separately.
Set
Set without tracks
Area of application
For door weights up to 26/36 kg, with soft closing mechanism (optional)
Running gear guided by
Friction bearing
Door stopper
Top clip-in door stopper, for sliding into running track
Door adjustment via
eccentric screw
Material/finish
Housing: Plastic Running gear: Zinc alloy Guide: Plastic Rollers: Plastic Axis: Steel
For door thickness min.
3/4"
Type of opening
linear
Height Adjustment
±2 mm
Number of Doors
2
