LCN 4041-DEL-RW/PA-BLACK 4041 Series Delayed Action Door Closer Black Painted
Item #: 4041-DEL-RW/PA-BLACK by LCN
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Finish
Black Painted
Grade
ANSI/BHMA Grade 1
Spring Size
1-6
Function
RW/PA-Regular Arm w/PA Shoe
Mount
Push or Pull Side
Finish Description
Black
Closer Options
Delayed Action
Closer Cover
Plastic Cover
Product Type
Door Closer/Holder/Stop
Series
4040XP Series
Application
Most Demanding High-Use-And-Abuse Applications
Hand
Non-Handed
Handing
Non-Handed
Warranty
30 year
Color
Black
Mounting Type
Push or Pull Side
Door Thickness
1-3/4 inch
Product Height
3-1/2 Inch
Product Length
12-1/4 Inch
Product Width
2-1/4 Inch
ADA Compliant
YES
Finish Family
Black
Included Components
Patented Green Dial Spring Force Indicator
Closer Arm Construction
Forged Steel
Product Material
Cast Iron
Standards
Grade 1 - ANSI A156.4, UL 10C, 100 Hour Salt Spray, Meets BAA - Buy American Act
Closer Arm Extension
11" (Hinge Pull, Top Jamb Push)
Closer Arm Type
Regular Arm with Parallel Arm Bracket
Closer Clearance
2-3/8" (Hinge Pull); 6" (Parallel Arm Push)
Closer Fluid Temperature Range
-30°F to 120°F
Closer Fluid
All Weather Liquid X Fluid
Closer Piston Diameter
1-1/2 Inch
Closer Pinion Diameter
3/4 Inch
Function Family
Non Hold Open Door Closer
Mounting Hole Size
2-1/4" x 5"
Templating
Peel-n-Stick
Fastener Type
Self Reaming and Tapping Screws
Features
Full Complement Bearing; Double Heat-Treated Steel Pinion Journal
Manufacturer Parent
Allegion
Closer Hold-Open
true
Delayed Action
true
Sub-Series
DC_Surface Mounted Closers_lcn_14
Door Size
5' (Interior); 4' (Exterior)
Maximum Door Opening
120°
Product Overview
4041 SeriesHeavy Duty Door Closer
The LCN 4041 Series is a non-handed surface mounted door closer. A wide choice of options, mounting accessories and ease of installation offer maximum versatility. The LCN 4041 Series is a heavy duty door closer designed to be used on aluminium, hollow metal or wood swinging commercial interior/exterior doors and is ideally suited for hospitals, educational, institutional and other high traffic applications.
Performance Features:- Universal, fully reversible, nonhanded door closer.
- Closer cylinder constructed of high strength cast iron for extra durability.
- Tested to 10,000,000 cycles.
- Fully adjustable 1-6 spring strength to suit door size and site conditions.
- Shipped set to size 3.
- Standard closer offers 3 installation options.
- Regular (Pull side)
- Top Jamb (Pull side)
- Parallel Arm (Push side)
- Independent adjustment valves for adjusting backcheck, closing and latching speeds.
- All adjustment valves are concealed behind the cover to prevent tampering.
- Joints in arms and shoe brackets adapt to uneven mounting surfaces.
- Fast adjust dial (fast accurate spring tension) to help installers accurately adjust the closer to match the conditions of the application. As spring power is adjusted, the size appears on the face of the dial.
- Stick-on template for fast, accurate installation. Cuts installation time in half.
- Closers installed according to LCN installation instructions require minimal periodic maintenance or adjustments.
- Timber or Metal
- External Door 610mm - 1219mm
- Internal Door 610mm - 1524mm
- Regular - Pull Side Mount
- Parallel Arm - Push Side Mount
- Top Jamb - Push Side Mount
- Closing Speed
- Latching Speed
- Backcheck
- 1-6 Adjustable
- Hold Open Arm
- Adaptor Plate
- Parallel Arm Drop Plate
- Square Metal Cover
- Aluminium
- Satin Stainless Steel
- Polished Stainless Steel
- 10 Years
