Von Duprin 230NL 313 230NL Night Latch Trim, Dark Bronze Painted
Item #: 230NL 313 by Von Duprin
UPC #: 043156602308
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Includes 10 gauge stainless steel escutcheon
- Overall measurements: 12.0625" Height X 3" Length
- Compatible with all 22 series exit devices
Material
Stainless Steel
Approved for Commercial Use
Yes
Door Thickness
1-3/4"
Width
3
Handing
Non-Handed
Handle Material
Metal
UL Listed
Yes
Product Class
Commercial
Theme
Commercial
BHMA Certification
Grade 1
ADA
Yes
Fire Rated
No
Panic Proof
Yes
Handle Style
Grip
Configuration
Exterior Trim
Exit Trim Function
Night Latch
Height
12.0625
Collection
230
Grade
Grade 1
Color
Dark Bronze Anodized Aluminum
Color Code
313
Package Volume
0
Package Qty
1
Trim Type
Nightlatch Pull
Base Material
Aluminum
Finish
Dark Bronze Painted
Warranty
3-year warranty
Pack Size
1
Builders Hardware Product Type
Exit Devices
Door Handing
Universal/Reversible
General Material
Aluminum
Hardware Finish Family
Bronze
Product Depth (in.)
11
Product Height (in.)
6
Product Width (in.)
4.75
Function
NL-Night Latch (Key Retracts Latchbolt)
Cylinder Type
Conventional or IC
Finish Description
Dark Bronze Painted
Product Type
Exit Device Trim
Series
22 Series Trim
Trim Design
Escutcheon with Pull Handle
UNSPSC
31162800
ADA Compliant
No
Finish Family
Dark Bronze
Product Material
10 Gauge Steel
Standards
ANSI/BHMA A156.3 (2014) Grade 1
Trim Style
NL
Cylinder Type Used
Rim
Device Trim Function
Key Retracts Latch Bolt
Device Pull Center To Center
5-1/2 Inch
Function Family
Night Latch Exit Device Trim
Device Trim ANSI Function
03
Product Projection
2 Inch
Trim Plate Width
3 Inch
Trim Plate Height
12-1/16 Inch
Trim Plate Thickness
3/32 Inch
Features
Flexibility; Versatile Design Enables You to Add Functionality to Existing Devices in a Cost-Effective Way
For Use With
22 Series Exit Devices
Hand
Non-Handed
Manufacturer Parent
Allegion
Sub-Series
EDT_Device_Trim_von_duprin_78
Product Overview
230NLNight Latch Trim
22 Series Optional Trim
Specifications: Trim description:- 230NL**
- 3" x 12 1/16" x 3/32"
- (76 x 306 x 2 mm)
- 5 1/2"
- (140 mm)
- 2"
- (51 mm)
- 03
- Rim
- 6
- 2
- *Sex Bolts are required for wood fire doors
- **ANSI/BHMA A156.3 (2008) Grade 1 Trim
