Schlage Residential J10 TOR 619 J Series Passage Lever, Mechanical Lock, Satin Nickel, Lever Handle, Metal, Residential, Grade 3 Grade
Item #: J10 TOR 619 by Schlage Residential
UPC #: 043156774562
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Hall/ Closet (Passage) Function - Both Knobs/Levers Always Unlocked
- Easy installation
- ADA Compliant: Yes
- Applications: Residential single- and multi-family doors
- ANSI/BHMA A156.36 Grade 3
- Reversible Handing
- Backset: Universal latches and deadbolts fit 2-3/8" (60mm) or 2-3/4" (70mm) backsets.
- Certifications: ANSI A156.2, 1996, Series 4000 Grade 2
- Includes All Mounting Hardware for Easy Installation
- Lifetime Mechanical & 5 Year Finish Warranty
- Door thickness range: 1-3/8" to 1-3/4" (35mm-44mm) standard
- UL Listed: Locks for up to three-hour fire doors available
Finish
Satin Nickel
Function
10-Hall/Closet
Series
J Series
Design
Torino
Handing
Reversible
Strike
Full Lip 2-1/4 Inch, Radius Corner
Backset
2-3/8 Inch or 2-3/4 Inch
Color
Satin Nickel Plated Clear Coated
Color Code
619/US15
Grade
ANSI/BHMA Grade 3
Finish Description
Satin Nickel
Lever Style
TOR-Torino
Rose/Escutcheon Trim
Round Rose
Product Type
Cylindrical Lock
Projection
2.8800
Door Thickness
1-3/8 to 1-3/4"
Bore Size
2.1250
Product Height
2-5/8 Inches
Product Length
4.0000
Included Components
Passage levers, roses, latch, strike, mounting hardware
Door Cross Bore
2.125 Inch
Product Material
Zinc
Box Length
6.6900
Box Width
5.7100
Box Height
3.0700
Strike Size
1-5/8 x 2-3/4"
Manufacturer Parent
Allegion
Faceplate Dimension
1/4"
Door Edge Bore
1 Inch
Latch Type
Spring Latch
Function Description
Latch retracted by knobs/levers at all times
ANSI Function
F75
Sub-Series
J10-TOR
Lever Style Family
Straight With Return Lever
ADA Compliant
YES
Box Dimensions (L x W x H)
3.07x5.71x6.69
Function Family
Passage/Hall/Closet
Standards
ANSI/BHMA A156.2-2011 Commercial Grade 3; ADA Compliant
Product Projection
2-7/8 Inch
Features
Lever Design Pairs Well With Transitional Styles Like Exotic Wood Grains and Neon Signs; Always Unlocked for Ease of Entry; Easy Installation With Screwdriver; Self-Aligning Screw Holes Make Installation Easy and Hassle-Free
Strike Type
Round Corner Full Lip
Warranty
Limited lifetime
Finish Family
Satin Nickel
Alternate Part Number-1
156597
Knob/Lever Design
Torino
Knob/Lever Style
Lever
Material
Metal
Dimensions
2.44 in L x 5.39 in W x 2.63 in H
Handle Type
Lever
Faceplate Size
1 x 2-1/4"
Commercial/Residential
Residential
Backset Size
2-3/8 x 2-3/4"
Security Grade
Grade 3
Cross Bore Diameter
2-1/8"
Latch Housing Diameter
7/8"
Throw Length
1/2"
Nomenclature
J10TOR619 LVR DR PASS SAT NIC
Bolt Throw Size
1/2"
Edge Bore Diameter
1"
Projection Size
1/2"
Lock Type
Mechanical
Dimension
4-1/2" Lever Length and 2-1/8" Projection with 2-5/8" Diameter Rose
Manufacturer Warranty
Limited Lifetime Mechanical and 5 Year Finish Warranty
Rose/Escutcheon Design
Round Rose
Door Range
1-3/8" to 1-3/4"
Hazardous Material
No
Strike Dimension
2-1/4" x 1-5/8" x 1-1/8" Lip
Cross Bore Size
2-1/8" Bore
Finish code
619
Latch Faceplate Dimension
Round Corner 1" x 2-1/4" Faceplate or 1" Collar
Lever Knob Design
Torino Lever
No of inners
1
Product Overview
LEVER DOOR PASS SATNIC TORINO
Specifications:
Specifications:
Application: For residential single and multi family doors
Torino lever hall and closet lock in satin nickel.
