Schlage J40 CNA 619 Corona Series J40 CNA 619 Privacy Lockset, Round Design, Knob Handle, Satin Nickel, Metal, Yes
Item #: J40 CNA 619 by Schlage Residential
UPC #: 043156772803
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Bed/Bath (Privacy) Function - Turn Button Locking, Turning Inside Turn Button Releases Inside Knob/Lever
- Easy installation
- turnbutton locking, can be locked from inside by turning interior turn
- Applications: Residential single and multi family doors
- Backset: Universal - fits either 2-3/8" or 2-3/4" backset
- ANSI/BHMA A156.36 Grade 3
- Reversible Handing
- Certifications: Commercial Standard Certification:ANSI/BHMA A156.2-2010 Grade 3 Residential Standard Certification:ANSI/BHMA A156.39-2015 Grade CCC in Security, Durability and Finish
- Door thickness range: 1-3/8" to 1-3/4" standard
- Includes All Mounting Hardware for Easy Installation
- Lifetime Mechanical & 5 Year Finish Warranty
- UL Listed: Box pack available
Finish
Satin Nickel
Function
40-Bed/Bath
Series
J Series
Design
Round
Handing
Reversible
Strike
Full Lip 2-1/4 Inch, Radius Corner
Backset
2-3/8 Inch or 2-3/4 Inch
Color
Satin Nickel Plated Clear Coated
Color Code
619/US15
Grade
ANSI/BHMA Grade 3
Finish Description
Satin Nickel
Knob style
CNA-Corona
Rose/Escutcheon Trim
Round Rose
Product Type
Cylindrical Lock
Projection
2.8800
Door Thickness
1-3/4 to 1-3/8"
Knob Diameter
2.0000
Bore Size
2.1250
Product Height
2-5/8 Inch
Included Components
Privacy Knobs; Roses; Latch; Strike; Mounting Hardware
Door Cross Bore
2.125 Inch
Product Material
Zinc
Box Length
6.7700
Box Width
3.2300
Box Height
2.7600
Returnable
Yes
Defective Code
A
Commercial or Residential
Residential
Lockset Type
Turn Button
Number in Package
1 pk
ADA Compliant
No
Sub Brand
Dexter
Indoor or Outdoor
Indoor
Maximum Door Thickness
1-3/4"
Style
Corona
Backset Dimension
2-3/8 or 2-3/4"
Packaging Type
Boxed
Minimum Door Thickness
1-3/8"
Door Direction
Right or Left Handed
Material
Metal
Each Weight
0.940 LB
Velocity
X
Hazardous Material
No
Application
Residential Single and Multi Family Doors
Warranty
5 Years Limited
ANSI Function
F76
Latch Type
Spring Latch
Strike Type
Round Corner Full Lip
Finish Family
Satin Nickel
Standards
ANSI/BHMA A156.2-2010
Function Description
Outside knob/lever locked by pushbutton on inside knob/lever. Rotating inside knob/lever or closing door releases/unlocks button. Emergency release in outside knob/lever.
For Door Thickness
1-3/8" to 1-3/4"
Function Family
Privacy/Bedroom/Bathroom
Product Projection
2.56 Inch
Manufacturer Parent
Allegion
Door Edge Bore
1 Inch
Box Dimensions (L x W x H)
2.76x3.23x6.77
Knob Style Family
Ball Knob
Sub-Series
RL_Knob_Locksets_Schlage_Residential_170
Features
Knob Design Pairs Well with Transitional Styles Flat Planes and Large Glass Windows; Locks From the Inside with a Turn-Button; Self-Aligning Screw Holes Make Installation Easy and Hassle-Free, Latch Dual Option( Round, Drive in)
Cylinder Included
No
Strike Size
1-5/8 x 2-3/4"
Alternate Part Number-1
135263
Latch Bolt Type
Deadlatch
Knob/Lever Design
Corona
Latch Bolt Faceplate Size
2-1/4" x 1"
Door Bore Size
2-1/8"
Lock Category
Cylindrical Lock
Door Thickness Min
1-3/8"
Latch Bolt Face Type
Drive-In, Round Corner, Square Corner
Latch Bolt Throw
1/2"
Rose/Escutcheon Style
Rose
Door Thickness Max
1-3/4"
Knob/Lever Style
Knob
Dimensions
2.5 in L x 2.63 in W x 2.63 in H
Faceplate Size
1 x 2-1/4"
Backset Size
2-3/8 2-3/4"
Cross Bore Diameter
2-1/8"
Latch Housing Diameter
7/8"
Throw Length
1/2"
Nomenclature
J40CNA619 KNOB PRIVACY SAT NIC
Backset Type
Adjustable
Edge Bore Diameter
1"
Projection Size
1/2"
Interior Locking
Yes
Handle Type
Knob
Height
2.76
Length
6.69
Width
3.35
Dimension
2" Knob Diameter and 2-3/4" Projection with 2-5/8" Diameter Rose
Manufacturer Warranty
Limited Lifetime Mechanical and 5 Year Finish Warranty
Rose/Escutcheon Design
Round Rose
Door Range
1-3/8" to 1-3/4"
Strike Dimension
2-1/4" x 1-5/8" x 1-1/8" Lip
Cross Bore Size
2-1/8" Bore
Finish code
619
Latch Faceplate Dimension
Round Corner 1" x 2-1/4" Faceplate or 1" Collar
Lever Knob Design
Corona Knob
No of inners
1
Product Overview
KNOB DOOR PRVCY SAT NIC CORONA
Specifications:
Specifications:
Application: For all standard door preparations
Includes: Mounting Hardware
Corona knob bed and bath lock in satin nickel.
