Schlage Residential JBE109 Billows Electronic Keypad Deadbolt Aged Bronze
Item #: JBE109-BIL-716 by Schlage Residential
Brand: Schlage Residential
UPC #: 194555005563
See reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- KEYPAD ACCESS: Electronic deadbolt stores up to 10 unique 4- to 8-digit access codes for keyless entry.
- Z-WAVE PLUS: Z-Wave Plus technology supports integration with select compatible home automation systems.
- ADJUSTABLE BACKSET: Universal backset adjusts to 2-3/8 inches or 2-3/4 inches for standard residential door preparation.
- DOOR COMPATIBILITY: Fits doors from 1-3/8 inches to 2 inches thick and is intended for residential single-family doors.
Finish
716 - Aged Bronze
Finish Description
Aged Bronze
Function
109-Keypad Connected Deadbolt
Grade
Grade 3
ADA Compliant
No
Keyblank Grouping
SCHR-C-5-1
Cylinder Type
Conventional Cylinder
Door Cross Bore
2.125 Inch
Included Components
Deadbolt; Roses; Latch; Strike; Mounting Hardware
Series
JBE Series
Keyway
Schlage C
Backset
Dual Option-Round, Drive-In
Rose/Escutcheon Trim
BIL-Billows
Product Type
Keypad Lock
Door Thickness
1-3/8" to 1-3/4"
Standards
ANSI/BHMA
Bore Size
2.1250
Keying Charges
Residential-Conventional
Strike
Round Corner with Reinforcer
Color Code
643E/US11/716
Finish Family
Antique Bronze
Function Family
Keypad Lock
Manufacturer Parent
Allegion
Door Edge Bore
1 Inch
Sub-Series
RH_Keypad_Touchscreen_Locks_schlage_residential_28
Alternate Part Number-1
178679
Collection
Billows
Package Height
3.622"
Package Length
7.441"
Package Width
5.591"
Item Weight
2.46 lbs
Power
Battery Operated
Keyed
Yes
Latch Faceplate
1" x 2-1/4" Radius deadbolt strike
Battery Operated
Yes
Reader Type
Keypad
Door Handing
Non-Handed
Door Thickness Range
1-3/8" To 2"
Door Strike
1" x 2-1/4"; Lever - radius full lip strike 1-1/2" x 2-3/4"
Segment
Door Hardware
Product Overview
OVERVIEW
Bye bye keys. The Schlage JBE109 Gatlin Trim Connected Keypad Deadbolt provides you with a convenient, easy to use keypad. Effortlessly secure and showcase your home with the modern design of the Gatlin trim. Access your lock from anywhere with Z-Wave Plus. No more hiding spare keys, just share up to 10 unique access codes with friends and family instead.
SPECIFICATIONS:
- ADA Compliant: No
- Applications: Residential single family doors
- Backset: Universal Backset Adjusts to 2-3/8" (60 mm) or 2-3/4" (70 mm)
- Battery: Uses 4 AA alkaline batteries
- Certifications: Commercial Standard Certification:ANSI/BHMA Commercial Grade 3
- Door thickness range: 1-3/8" to 2"
- Exterior Dimensions: 4.15" x 2.68" x 0.83"
- Interior Dimensions: 5.16" x 2.68" x 1.71"
- Keying: 5-pin tumbler, C Keyway, 1 key included
- Operating Temperatures: Outside escutcheon: -35C to 66C,Inside escutcheon: 0C to 49C
- Warranty: Limited Lifetime Mechanical Warranty, 5-Year Finish Warranty and 1-Year Electronics Warranty
- Codes: 10
FEATURES:
- Sleek, modern style keypad deadbolt lock
- Z-Wave Plus technology offers enhanced security and integration with select home automation systems
- Saves up to 10 unique access codes
- Uses 4-8 digit access codes
- Backlit keypad with silicone buttons
- One-Touch Locking
- Offers added durability with premium metal interior
- Withstands heavy-duty impacts
- Installs in minutes with just a screwdriver
- No hardwiring needed
- Guaranteed to fit on standard doors
- Meets all BHMA Grade 3 security and performance standards
- Certified Commercial Grade 3
- Limited lifetime mechanical, 5-year limited finish and 1-year limited electronic warranty
