Durability - 500,000 Life Cycles. Releases Under Slight Door Pre-Load. Holding Force - 1000 lbs. Tall Latch Cavity. Non Handed Operation. Screw Terminals - Quick Connection.
1001-2 (Brass Powder Coated) 1001-2C (Satin Chrome or - BHMA652) 1002A-2 (Aluminum Powder Coated) 1002-2DB (Dark Bronze Powder Coated)
DK Hardware Professional Tax Exempt? Net 30? - DK Net Terms
Roll over image to zoom in
Product Features
Product Overview
Related Videos
Reviews
Questions & Answers
Trine Access Technology 1001-2C-14-24 Electric Strike, 16-24VAC/DC, Fail Secure, 5-7/8" x 1-1/4" Faceplate, up to 5/8" Throw, Satin Chrome
Item #: 1001-2C-14-24 by Trine Access Technology
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Alternate Part Number-1
129994
Voltage
16-24V
Handing
Non-Handed
Faceplate Size
5-7/8" x 1-1/4"
Throw
5/8"
Faceplate Style
Square Corner
Lock Category
Cylindrical
Fail Status
Fail Secure
Product Overview
Trines 1000 Series Electric Strikes
1001-2
For use in new or replacement installations in wood and metal jambs. For use with locksets having up to 5/8" throw, based on 1/8" door gap.
Steel Face Plate 5-7/8" x 1-1/4" – Narrow Style Face Plate – Mortise Backset 1-1/2" – Cavity Depth 9/16" – Cavity Width 9/16" – Cavity Height 1-11/16"
1002-2
For use in new or replacement installations in wood and metal jambs. Auxiliary lever ramps for use with locksets which contain dead locking levers. For use with locksets having up to 5/8" throw, based on 1/8" door gap.
Face Plate 7-15/16" x 1-7/16" – Auxiliary Ramp 2-7/8" Height – Mortise Backset 1-1/2" – Cavity Depth 9/16" – Cavity Width 9/16" – Cavity Height 1-11/16"
1000 SERIES FEATURES:
ELECTRICAL CHARACTERISTICS
| Voltage | Amps | Ohms | Duty | Sound |
|---|---|---|---|---|
| 6-12VAC | 0.495 - 1.500 | 8 | Intermittent | Buzz |
| 6-12VDC | 0.750 - 1.200 | 8 | Continuous | Silent |
| 14-24VAC | 0.270 - 0.480 | 50.0 | Intermittent | Buzz |
| 14-24VDC | 0.380 - 0.610 | 50.0 | Continuous | Silent |
FINISHES
