The CRL Vienna Series of professional Hinges is able to accommodate 3/8" (10 mm) to 1/2" (12 mm) glass. A variety of six styles gives design flexibility, including three different Wall Mount and three different Glass-to-Glass types. Vienna Hinges are self-centering and contain a Reversible 5 degree Pivot Pin. In addition, Custom Pivot Pins are available to accommodate "off-angle" installations. Made of solid brass with all moving parts (pins and springs) in stainless steel.
DK Hardware Professional Tax Exempt? Net 30? - DK Net Terms
Roll over image to zoom in
Product Features
Product Overview
Related Videos
Reviews
Questions & Answers
CRL V1E545CH Polished Chrome Vienna 135 degree Glass to Glass with 5 degree Offset Hinge
Item #: V1E545CH by CR Laurence
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Self-Centering with Reversible 5 Degree Pivot Pin
- 5 Degree Pre-Set Model (Factory Set for 5 Degree Tighter Closure Into Shower Interior)
- Three Year Warranty
Finish
Polished Chrome
Mounting Type
Glass To Glass
Material
Brass
Back Plate
Offset
Glazing Thickness
3/8, 1/2
Edge Profile
Square
Adjustable
No
Finish/Color
Polished Chrome
Series
Vienna
Maximum Door Width -1/2 Glass
32"
Width - Sidelite Portion
2-11/16"
Self-Centering
Yes
Maximum Door Width - 3/8 Glass
34"
5 Degree Pre-Set
Yes
Maximum Door Weight - 3 Hinges
130 Lbs.
Maximum Door Weight - 2 Hinges
100 Lbs.
Width - Door Portion
2-1/4"
Glass To Glass Angle
135 degrees
Mounting Style
Glass To Glass
Maximum Door Width
36
Maximum Door Width - 1/2 Glass
32
Width - Sidelite Portion (Inch
2-11/16
Maximum Door Weight - 2 Hinges
100 lbs. (45.4 kg)
Maximum Door Weight - 3 Hinges
130 lbs. (59 kg)
Opening Style
Swing(side)
Enclosure Type
Tailor Made Solutions
Design Style
Squared
Product Overview
The CRL Vienna Series of professional Hinges is able to accommodate 3/8" (10 mm) to 1/2" (12 mm) glass. A variety of six styles gives design flexibility, including three different Wall Mount and three different Glass-to-Glass types. Vienna Hinges are self-centering and contain a Reversible 5 degree Pivot Pin. In addition, Custom Pivot Pins are available to accommodate "off-angle" installations. Made of solid brass with all moving parts (pins and springs) in stainless steel.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
