30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Length (mm)
6.90
Number of Cutting Edges
4
Thickness (mm)
2.7500
Insert Material
Solid Carbide
Series
CI
Coating/Finish
CVD
Corner Radius (Decimal Inch)
0.0197
Length (Decimal Inch - 4 Decimals)
0.2717
Thickness (Decimal Inch - 4 Decimals)
0.1083
UNSPSC Code
23291601
Vendor Drop Ship
N
Width (Decimal Inch - 4 Decimals)
0.1102
Width (mm - 2 Decimals)
2.80
Insert Holding Method
Screw
Maximum Depth of Cut (Decimal Inch)
0.0315
Rake
Positive
Insert Hand
Right Hand
Inscribed Circle (Decimal Inch)
0.2717
Insert Shape
Square
Insert Style
XPLT
Insert Size Code
07
Relief Angle
11.000
Maximum Depth of Cut (mm)
0.80
Manufacturer Grade
ACS35M
Single or Double Sided Insert
Single
Cutter Series Compatibility
XPLT
Inscribed Circle (mm)
6.90
Corner Radius (mm)
0.50
Iso Code
XPLT070305ERSCM
