PDLN4500 Networx Trilogy Electronic Digital Proximity Satin Chrome

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Alarm Lock PDLN4500DBL/26D PDLN4500 Networx Trilogy Electronic Digital Proximity Satin Chrome

Item #: PDLN4500DBL/26D by Alarm Lock

See reviewsSee reviews
See reviews summary
In Stock

$1,443.52

/each
SAVE UP TO 144.35

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business dayIn stock: 37 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Finish

Satin Chrome

Finish Description

Satin Chrome

Product Type

Electronic Cylindrical Lock

Series

PDL Series

Alternate Part Number-1

181694

Grade

ANSI/BHMA Grade 1

Application

School

Hand

Left Hand

Backset

2-3/4 Inch

Handing

LH

Warranty

2 Year

Operating Temperature

-31 to 151°F

Color Code

626/US26D

Function

Digital Lock

Door Thickness

1-5/8 to 1-7/8 Inch

Cylinder Type

Mortise

Latch Throw

3/4 Inch

ADA Compliant

YES

Finish Family

Satin Chrome

Included Components

(5) AA Alkaline Batteries; Cloverleaf Cam

Strike Size

1-1/4" x 4-7/8"

Lever Projection

1 Inch

Standards

BHMA Certified; UL Listed; FCC Certified

Function Description

Authorized Digital Code/Prox Technology ID Enables Outside Lever to Retract Latchbolt, Deadlocking Latch and Deadbolt. Inside Lever is Always in Passage Mode and Permits Instant Egress; Push Button on Inside Door to Temporarily Lock-Out Keypad Codes

Function Family

Digital Lock

Features

Weatherproof; Standard ANSI A115 Series Prep; 12-Button Vandal-Proof Metal Keypad; 2000 User Codes; 40000 Audit Trail; 500 Scheduled Events; Battery 60000 Cycles; Programmable Relay; Multi-Status LED Indicator; Self-Stick Instructional Signage

Manufacturer Parent

Napco Security Technologies

Sub-Series

PDLN4500DBL/26D

Product Overview
PDLN4500Networx Mortise Prox/Digital Privacy

Electronic battery operated digital proximity lock. Holds up to 2000 codes, Master, Management, Supervisor & basic user. 500 event schedule, real time clock & 40,000 event audit trail. Will read most HID card and keyfob formats. Privacy feature will lock out all users for a programmed amount of time. Residency feature allows exiting without having to lock the door.

Specifications: Door Thickness:
  • Fits 1 5/8" to 1 7/8"
Backset:
  • 2 3/4" standard
Strike:
  • 1 1/4" x 4 7/8" strike included
Handing:
  • Specify RH or LH when ordering. Lock is reversible in the field.
Power:
  • 5 AA alkaline batteries (included)
Door Prep:
  • Standard ANSI AUS mortise prep, modified by adding additional through-bolt holes
Compliances:
  • Steelcase lock body meets BHMA specifications for Grade 1 locks UL Listed 10C Positive Pressure Specification. FCC Certified ADA compliant levers
Functions:
  • Deadbolt function only. Features stainless steel deadbolt with 1" (2.55cm) projection, latch bolt with 3/4" (1.91cm) projection and deadlocking latch. Deadbolt may be projected from key cylinder from outside door or turn-piece from inside door.
Cylinder:
  • 1 3/8" (3.5cm) mortise cylinder supplied. Will accept 1 3/8" to 1 1/2" (3.5 - 3.8cm) mortise cylinder.
Cams:
  • Supplied with cloverleaf cam. Cams for other manufacturer's cylinder are available.
Finishes:
  • 26D - Satin Chrome
