30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Material
Powdered Metal
Flute Style
Slow
Material Application
Nickel Alloy
Helix Angle
10
Number of Flutes
3
Thread Direction
Right Hand
Series
T692
Thread Length (mm)
12.00
Thread Standard
UNC
Chamfer
Modified Bottoming
Class Of Fit
2B/3B
Coating/Finish
Multi-layer
Coolant Through
No
Overall Length (Decimal Inch)
2.3700
Overall Length (Inch)
2-3/8
Primary Workpiece Material
High-Temp Alloy
Primary Workpiece Material Code
S
Shank Diameter (Decimal Inch)
0.1940
Shank Diameter (mm)
4.93
Tapping Depth (mm)
23.00
Thread Length (Decimal Inch)
0.4700
Thread Size (Inch)
#10-24
UNSPSC Code
23241600
Vendor Drop Ship
N
Flute Direction
Right Hand
Neck Length (Decimal Inch)
0.4400
Proprietary Coating/Finish
Nitride
Tapping Depth (Decimal Inch)
0.9100
Thread Limit
H3
