Onward 246BP96B90BC RUSTIC Bypass Barndoor Kit with Track Matte Black
Item #: 246BP96B90BC by Richelieu Hardware
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Finish
Matte Black
Overall Length
96 in
Style
Barn Door
Application
Closet and Walk-In Closet, Pantry, Barn Door
Load Capacity
220 lb
Door Thickness
1 3/8 to 1 3/4 in
Door Width
30 to 48 in
Door Height
36 to 108 in
Number of Doors
2
Door Material
Wood
Detailed Door Movement
Bypassing
Door Movement
Straight Sliding
Manufacturing Material
Steel
Track Mounting
Wall Mount
Product Overview
Single track
The RUSTIC Bypass Barndoor Kit with track is for two sliding wood doors weighing up to 220 lb (100 kg) each. The Strap-Mount hangers and rollers are surface-mounted to the face of the door and travel on the same single track.
Features:
- Select from two finishes: Matte Black and Satin Nickel
- For door thickness 1-3/8 to 1-3/4 in (35 to 45 mm)
- Flexible floor guides for different door thicknesses and no grooves in the door required.
- Select from three track lengths :
60 in (1524 mm)
72 in (1830 mm)
96 in (2438 mm)
- Each KIT includes two rectangular recessed door pulls
- The ends of the tracks are pre-drilled to accept connector plates to add and extend the track
This is an ideal solution for creating a feature wall for closets, storage rooms, pantries, room dividers, and moveable partitions over a large door opening.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Without a bottom guide or groove at the bottom of the door.
Advantages And Benefits
Smooth running ball bearing rollers
Two doors travel on the same single-track
Includes two rectangular recessed door pulls
Flexible floor guides for different door thicknesses and no grooves in the door required
Three rail lengths to choose from:
60 in (1524 mm)
72 in (1830 mm)
96 in (2438 mm)
Included Product(S)
2 straight surface hangers and wheel
2 cranked surface hangers and wheel
2 stoppers
2 floor guides (4 parts)
1 Flat bar rail
4 wall mount with lag bolts
2 anti-jump discs
2 rectangular recessed door pull
8 through bolts with nuts M10 x 55 mm
8 through bolts with nuts M10 x 60 mm
Important Information
Use metric dimensions for greater accuracy during installation.
Please make sure to read the entirety of the installation manual before proceeding with the installation.
Always remove debris/dust/residues (sawdust and/or aluminum) from all tracks and guide channels using a dry cloth during installation and before operating the system.
Never spray lubricant on this product.
Do not exceed stated limitations and parameters. This will cause early wear and performance failure.
The RUSTIC Bypass Barndoor Kit with track is for two sliding wood doors weighing up to 220 lb (100 kg) each. The Strap-Mount hangers and rollers are surface-mounted to the face of the door and travel on the same single track.
Features:
- Select from two finishes: Matte Black and Satin Nickel
- For door thickness 1-3/8 to 1-3/4 in (35 to 45 mm)
- Flexible floor guides for different door thicknesses and no grooves in the door required.
- Select from three track lengths :
60 in (1524 mm)
72 in (1830 mm)
96 in (2438 mm)
- Each KIT includes two rectangular recessed door pulls
- The ends of the tracks are pre-drilled to accept connector plates to add and extend the track
This is an ideal solution for creating a feature wall for closets, storage rooms, pantries, room dividers, and moveable partitions over a large door opening.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Without a bottom guide or groove at the bottom of the door.
Advantages And Benefits
Smooth running ball bearing rollers
Two doors travel on the same single-track
Includes two rectangular recessed door pulls
Flexible floor guides for different door thicknesses and no grooves in the door required
Three rail lengths to choose from:
60 in (1524 mm)
72 in (1830 mm)
96 in (2438 mm)
Included Product(S)
2 straight surface hangers and wheel
2 cranked surface hangers and wheel
2 stoppers
2 floor guides (4 parts)
1 Flat bar rail
4 wall mount with lag bolts
2 anti-jump discs
2 rectangular recessed door pull
8 through bolts with nuts M10 x 55 mm
8 through bolts with nuts M10 x 60 mm
Important Information
Use metric dimensions for greater accuracy during installation.
Please make sure to read the entirety of the installation manual before proceeding with the installation.
Always remove debris/dust/residues (sawdust and/or aluminum) from all tracks and guide channels using a dry cloth during installation and before operating the system.
Never spray lubricant on this product.
Do not exceed stated limitations and parameters. This will cause early wear and performance failure.
