CRL CD10X10SA Satin Anodized 10" Glass Mounted Offset Pull Handle

Item #: CD10X10SA by CR Laurence

See reviews See reviews
In Stock

$129.14

/each
SAVE UP TO 12.91

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business day
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
  • Use Monolithic Tempered Glass
  • Complete with Matching Finish Metal Washers and Through-Bolts for Mounting
  • For Use with 3/8" to 3/4" (10 to 19 mm) Glass
  • Stocked in Up to Five Architectural Finishes

Shipping Weight

4 lb (1.81kg)

Mounting Holes Center-to-Center

10" (254 mm)

Finish

Satin Anodized

Overall Length

10

Center to Center

10

Glazing Thickness

3/8 To 3/4

Finish/Color

Satin Anodized

Style Washers

Yes

Mounting Hole Diameter (Inches)

5/8

Style Washer Diameter (Inches)

1-1/4

Diameter

1"

Mounting Type

Back-To-Back

Mounting Center To Center (Inches)

10

Mounting Hole Diameter

5/8 in. (16 mm)

Mounting Center To Center

10 in. (254 mm)

Style Washer Diameter

1-1/4 in. (32 mm)


This CRL Glass Mounted Standard Pull Handle is available in three sizes and in many different architectural finishes.
SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) Glass
Construction: 1" (25 mm) Diameter Stainless Steel or Brass Tubing.
  • *1-1/4" (32 mm) Diameter Stainless Steel (Cat. No. CD24X24BS125 Model only).
    Offset: 3" (76 mm) Center-to-Center
    Glass Fabrication Required: Two 5/8" (16 mm) Diameter Holes
    INCLUDES:
    2 Each: Through-Bolts for Glass Mounting
    4 Each: 1-1/4" (32 mm) Diameter Matching Finish
    Metal Washers and Rubber Gaskets

    .
