Square D HOM612L100FCP Homeline Load Center, 100 A, 6 -Space, 12 -Circuit, Main Lug, NEMA 1 Enclosure, Gray
Item #: HOM612L100FCP by SQUARE D
UPC #: 047569071249
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
- Accommodates plug-on secondary surge arrestor
- Overhead/underground feed simply by rotating the device before installing
- Flush mount device cover without a door
- Thermoplastic interior assembly is among the most rugged in the industry
- Slot/square drive screws let you use either standard flat blade screwdriver or square-head driver for positive drive and proper torque
- Includes flush mount cover without a door
- Single phase
- Three ground bar mounting locations (left, right and end) let you pick the easiest spot to wire
- Accommodates plug-on secondary surge arrestor (sold separately)
Warranty
Square D warrants its single phase load centers, in a residential application, to be free from defects in material and workmanship under normal care and proper usage for a period of 10 years from the date of installation for HOMELINE load centers when used with the appropriate Square D HOMELINE branch circuit breakers.
Pack Size
1
Returnable
Yes
UL Listed
Yes
Height
4.30
Defective Code
A
Breakers Included
Yes
Number of Spaces
6
Maximum Number of Circuits
12 circuits
Width
10.50
Circuit Protection Type
Main Lug
Sub Brand
HomeLine
Mounting Type
Plug
Indoor or Outdoor
Indoor
Volts
120/240 V
Packaging Type
Boxed
Depth
3.8"
Product Type
Main Lug Load Center
AMPS
100 amps
Each Weight
6.700 LB
Velocity
C
Hazardous Material
No
UNSPSC
39121101
Alternative UPC
785901071242
Length
14.90
ECCN
EAR99
Country Origin Code
MX
Finish
Baked Enamel
Color
Gray
Bus Bar Material
Aluminum
Number of Circuits
12
Breaker/Load Center Type
Main Lug
Enclosure Type
NEMA 1
Current Rating
100 A
Cable Size
8 to 1 AWG
Interrupt Rating
10 kA
Nomenclature
HOM612L100FCP 100A LOADCENTER
Cover/Lid Type
Flush
Number of Phases
1
Wiring Configuration
3-wire
Main lug indoor load center, 100 A, 6 space/12 circuit. 1-1/2 in knockouts in the top and bottom end walls to allow for use with either overhead or underground fed electrical wiring. 22,000 short circuit current rating (SCCR) and can be fitted with a secondary surge arrestor (not included) for added protection. Single phase, 3-wire, solid neutral. UL listed.
