Corbin Russwin DL3213 605 CLS7 Deadlock Bright Brass

Item #: DL3213 605 CLS7 by Corbin Russwin

Item Discontinued!
See reviewsSee reviews
See reviews summary

The item is currently out of stock and it may or may not be restocked
OUT OF STOCK

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features
  • Handing Non-handed.
  • Door Thickness Standard: 1-3/4" (44mm). Optional door thicknesses available
  • Backset Standard: 2-3/4" (70mm) Optional: 2-3/8" (60mm)
  • Front Standard: brass or stainless steel, 2-1/4" (57mm) x 1-1/8" (29mm). Optional: 1" width; see Quick Codes.
  • Deadbolt 1" throw, solid steel deadbolt with hardened, free spinning, steel pin insert.
  • Strike Standard; 2-3/4" (70mm) x 1-1/8" (29mm). Optional strikes and wrought boxes available; see Strikes, this page.
  • Cylinder Standard: brass, 6-pin, L4 keyway, 0-bitted. Security cylinder optional; see Quick Codes.
  • Keys Two nickel silver standard.
  • Keying Features Available Master keying Construction master keying Security Visual key control Concealed key control
  • Warranty One-year limited.

Thickness

1-3/4 In.

Package Volume

126

Color

Bright Brass

Function

13-Single Cylinder Deadbolt

Latch Type

Deadbolt

Burglar Rated

No

Hand

Not Handed

Fire Rated

3 Hours {A}

Special Marks

Full size/large format interchangeable core, Fire rated 3 Hours {A}

Dust Box

None

Strike Width

1-1/8 In.

Latch Backset Dim

2-3/4 In.

Cylinder Type

Sargent LFIC Less Core

Package Qty

1

Package Height

4"

Screws

Combination

Package Width

4"

Bolt Protection

1 In.

Color Code

605/US3

Strike Type

Flat

Base Material

Brass

Strike Height

2-3/4 In.

Package Length

7.875"

Product Overview

Single Cylinder, Large Format Interchangeable Less Core, Bright Brass

Corbin Russwin is pleased to introduce the DL2200 and DL3200 cylindrical deadlocks. These easy to install deadlocks feature a solid steel deadbolt - with a hardened, free spinning, steel pin insert - and a 1" throw. Ideal for a variety of applications, the DL2200 is certified to 156.5 Grade 2 standards and the DL3200 is certified to 156.5 Grade 1 standards. Features Solid steel deadbolt with a hardened, free spinning, steel pin insert and a 1" throw 1-3/4" door thickness standard; additional door thicknesses offered Available in 2-3/4" or 2-3/8" backsets Standard 161 door prep Pyramid cylinders optional UL listed for use with Fire Rated doors

Non-handed cylindrical deadlock.
